SPT1437 Vet Battery Operated Acetabular Reaming System AO Types


Specifications :

Power Output : ≥ 65W
Speed : 0-280(r.p.m)
Torque : 5.5Nm
Noise : ≤ 40 (db)
Battery : 9.6 (V), Ni-Mh, 1800 mA/h
Sterilization : 135° C

   Usage: Joint Operation. High torque, Low speed, stepless variable speed control.

Set Consisting of : Units
SPT1437.1 - Battery powered handpiece with AO/Synthes Reamer Adapter 1
SPT141 - Battery 2
SPT142 - Battery Charger 220V, 50Hz 1
SPT143 - Sterilizing Ring 2
SPT144 - Jacub Chuck & Key 1
SPT1437 Vet Battery Operated Acetabular Reaming System AO Types

SPT1438 Vet Battery Operated Acetabular Reaming System


Same as SPT1437 but with Stryker Reamer Adapter

SPT37 Vet Battery Operated Acetabular Reaming System AO Types


    Same as SPT1437 but with below specifications

Specifications :

Power Output : ≥85W
Speed : 0-320(r.p.m)
Torque : 7.8 Nm
Noise : ≤ 40 (db)
Battery : 14.4 (V), Ni-Mh, 1800 mA/h
Sterilization : 155° C

   Usage: Joint Operation. High torque, Low speed, stepless variable speed control.

SPT37 Vet Battery Operated Acetabular Reaming System AO Types

SPT38 Vet Battery Operated Acetabular Reaming System


Same as SPT37 but with Stryker Reamer Adapter

SPT637 Vet Battery Operated Acetabular Reaming System, High Torque / High Power


    Same as SPT1437 but with below specifications

Specifications :

Power Output : ≥ 95W
Speed : 0-350(r.p.m)
Torque : 9.0Nm
Noise : ≤ 40 (db)
Battery : 14.4 (V), Ni-Mh, 1800 mA/h
Sterilization : 135° C

   Usage: Joint Operation. High torque, Low speed, stepless variable speed control.

SPT637 Vet Battery Operated Acetabular Reaming System, High Torque / High Power

SPT638 Vet Battery Operated Acetabular Reaming System, High Torque / High Power


    Same as SPT637 but with Stryker Reamer Adapter

To be Ordered Separately at Extra Cost
SPT37.2 - Acetabulum Reamer Shaft (AO/Synthes Type) for SPT1437 / SPT37/ SPT637
SPT38.2 - Acetabulum Reamer Shaft (Stryker Type) for SPT1438 / SPT38/ SPT638
SPT638 Vet Battery Operated Acetabular Reaming System, High Torque / High Power

Acetabulum Reamer (AO/Synthes Type): SPT37.036 to SPT37.064
Code No. Size mm Code No. Size mm Code No. Size mm
SPT37.036 36 SPT37.046 46 SPT37.056 56
SPT37.038 38 SPT37.048 48 SPT37.058 58
SPT37.040 40 SPT37.050 50 SPT37.060 60
SPT37.042 42 SPT37.052 52 SPT37.062 62
SPT37.044 44 SPT37.054 54 SPT37.064 64

Acetabulum Reamer (Stryker Type): SPT38.036 to SPT38.064
Code No. Size mm Code No. Size mm Code No. Size mm
SPT38.036 36 SPT38.046 46 SPT38.056 56
SPT38.038 38 SPT38.048 48 SPT38.058 58
SPT38.040 40 SPT38.050 50 SPT38.060 60
SPT38.042 42 SPT38.052 52 SPT38.062 62
SPT38.044 44 SPT38.054 54 SPT38.064 64

OPTIONAL Adapters for SPT1437 / SPT37 & SPT637 (To be Ordered Separately at Extra Cost)
SPT08 - Hudson Adapter
SPT09 - Zimmer Adapter
SPT10 - Link Adapter
SPT11 - Aesculup Adapter
SPT12 - Stryker Adapter

OPTIONAL Adapters for SPT1438 / SPT38 & SPT638 (To be Ordered Separately at Extra Cost)
SPT13 - Link Adapter
SPT14 - Aesculup Adapter
SPT15 - AO/Synthes Adapter
